Overview
The Vickers Valiant is a high-altitude strategic bomber aircraft designed by Sir George Edwards and manufactured by Vickers-Armstrong. It was one of the V bomber aircraft of the Royal Air Force during the 1950s and 1960s. The Valiant was introduced in 1955 and was the first among the V bombers to enter service.
Specifications
Units
- Engine
- —
- Engine type
- Jet
- Thrust
- 10,000 lbf · 44 kN
- Avionics
- GE Aviation Systems, Green Satin doppler radar, Gee radio navigation, (ADF), VOR/Distance Measuring Equipment (DME)
- Wing tips
- No winglets
- Seats
- 5
- Crew
- —
- Cabin width
- —
- Cabin height
- —
- Cabin length
- —
- Exterior length
- 108 ft 3 in · 33.00 m
- Tail height
- 32 ft 2 in · 9.80 m
- Fuselage diameter
- 10 ft 10 in · 3.30 m
- Wing span
- 114 ft 2 in · 34.80 m
- Baggage volume
- —
- Gross weight
- —
- Empty weight
- —
- Max takeoff weight
- 140,000 lb · 63,500 kg
- Max landing weight
- —
- Max payload
- 64,000 lb · 29,000 kg
- Fuel capacity
- Max cruise speed
- 493 kt · 567 mph · 913 km/h
- Maximum speed
- —
- Cruise speed
- —
- Approach speed
- —
- Range
- 3,900 nm · 4,490 mi · 7,220 km
- Fuel burn
- —
- Ceiling
- 54,000 ft · 16,500 m
- Rate of climb
- 4,000 ft/min · 20 m/s
- Takeoff distance
- —
- Landing distance
- —
Gallery
(/)
tap to zoom
(/)
Operational Context
On May 18, 1951, the WB210, the first Valiant prototype conducted its first flight piloted by Captain Joseph Mutt Summers with his co-pilot, Gabe Jock Bryce. After a month, Type 660 was designated the official name Valiant where it had been chosen during a survey with employees of the company.
On April 11, 1952, the second prototype with serial number EB215 designated as Type 667 took its first flight. It was powered by RA.7 Avon engines with a maximum thrust of 7,500 lbf each. It was also designed with circular air inlets that replaced the slim air inlets of Type 660. This was designed to provide enough air to the engines.
On September 4, 1953, the third prototype referred to as Valiant B.2 with serial number WJ954 conducted its first flight. It was famous as the Black Bomber because of its glossy black paint for night operations. It had a greater performance compared to the first two prototypes and can operate at maximum power at sea level.
It was utilized for testing for several years such as rocket tests to improve takeoff. On December 21, 1953, the first production Valiant took to the skies for the first time and on February 8, 1955, it was delivered to the Royal Air Force, its launch customer. The Vickers Valiant was produced from 1951 to 1957.
The Vickers Valiant has an external length of 33 meters, an external height of 5.3 meters, a tail height of 9.8 meters, and a fuselage diameter of 3.3 meters. It has a wingspan of 34.8 meters, a wing area of 219.4 square meters, and a wheelbase of 7.8 meters. It can accommodate five crew members including two pilots, two navigators, and an air electronics officer.
The aircraft has a maximum speed of 493 knots at 30,000 feet and a travel range of 3,900 nautical miles with underwing tanks. It can fly up to 54,000 feet and can climb up to 4,000 feet per minute.
