Supermarine Scimitar

Supermarine naval strike fighter introduced in 1957

Overview

Supermarine United Kingdom 1956–1961

The Supermarine Scimitar was built by the British aircraft manufacturer Supermarine as a naval strike fighter during the mid-1950s. It was intended for the Royal Navy Fleet Air Arm and first flew in January 1956. The aircraft was introduced and delivered in 1957 and was retired in 1969. It was in service with the Royal Navy from 1958 to 1969 before being replaced by the Blackburn Buccaneer. A total number of seventy-six aircraft were built.

Specifications

Units
Engine
2 × Rolls-Royce Avon 202
Engine type
Jet
Thrust
2 × 11,250 lbf · 50 kN
Avionics
—
Wing tips
No winglets
Seats
1
Crew
—
Cabin width
—
Cabin height
—
Cabin length
—
Exterior length
55 ft 4 in  ·  16.87 m
Tail height
17 ft 4 in  ·  5.28 m
Fuselage diameter
—
Wing span
37 ft 2 in  ·  11.33 m
Baggage volume
—
Gross weight
—
Empty weight
—
Max takeoff weight
34,200 lb  ·  15,500 kg
Max landing weight
—
Max payload
4,200 lb  ·  1,900 kg
Fuel capacity
1,280 gal · 4,800 L · 3,900 kg (Jet A)
Max cruise speed
640 kt  ·  736 mph  ·  1,185 km/h
Maximum speed
—
Cruise speed
—
Approach speed
—
Range
1,237 nm  ·  1,420 mi  ·  2,290 km
Fuel burn
—
Ceiling
46,000 ft  ·  14,000 m
Rate of climb
6,751 ft/min  ·  34 m/s
Takeoff distance
—
Landing distance
—
(/) tap to zoom
(/)
Supermarine Scimitar F1

Operational Context

The Supermarine Scimitar was developed from numerous naval jet aircraft designs of the manufacturing company, originally to a specification for a fighter aircraft without an undercarriage that can land on flexible sprung flight decks, that would have a lighter and less-complicated structure. On January 19, 1956, the first of the prototype designated as Type 544 took to the air for the first time. On January 11, 1957, the first production aircraft performed its maiden flight. The aircraft was mainly used by the Royal Navy and has a total number of seventy-six Scimitars built.

The Scimitar is a single-seat naval strike fighter with an external length of 16.84 meters, an external height of 3.57 meters, a tail height of 5.28 meters, and a wheelbase of 4.85 meters. It has a wingspan of 11.33 meters and a wing area of 45.1 square meters. The empty weight is 10,869 kg and the gross weight is 15,513 kg. It has a maximum payload of 1,900 kg and a fuel tank capacity of 1,276 US gal.

The aircraft is powered by twin Rolls-Royce Avon 202 turbojet engines. It is a combination of a fifteen-stage axial compressor with a combustion system and a two-stage axial flow turbine. Each engine produces a maximum takeoff thrust of 11,250 lbf. The Scimitar has a maximum speed of 640 knots at sea level and a travel range of 1,237 nautical miles. It can fly up to 46,000 feet and can climb at a rate of 6,751 feet per minute. It is loaded with four 30 mm ADEN cannons with 160 rounds per gun and four hardpoints with provisions to carry four 454 kg of bombs or four AGM-12 Bullpup air-to-ground missiles or AIM-9 Sidewinder air-to-air missiles. It could also carry up to sixteen 2 or 3-inch unguided rockets (four each pylon) and a single Red Beard freefall nuclear bomb.
