Douglas F4D Skyray

First fighter aircraft that could surpass Mach 1 in level flight

Overview

Douglas United States ICAO: F4D 1950–1958

The F4D Skyray holds the distinction of being the first carrier-launched aircraft to hold the worlds absolute speed record at 752.943 miles per hour. It was also the first fighter aircraft of the United States Navy as well as the United States Marine Corps that could surpass Mach 1 in level flight. The aircraft never entered warfare and was the final fighter aircraft manufactured by the Douglas Aircraft Company before the merging with McDonnell Aircraft.

Live Fleet Activity (F4D)

📡

Fetching live data…

Specifications

Units
Engine
1 × Pratt & Whitney J57-P-8
Engine type
Jet
Thrust
16,000 lbf · 71 kN
Avionics
—
Wing tips
No winglets
Seats
1
Crew
—
Cabin width
—
Cabin height
—
Cabin length
—
Exterior length
45 ft 3 in  ·  13.80 m
Tail height
13 ft 0 in  ·  3.96 m
Fuselage diameter
3 ft 3 in  ·  1.00 m
Wing span
33 ft 6 in  ·  10.21 m
Baggage volume
—
Gross weight
—
Empty weight
—
Max takeoff weight
27,100 lb  ·  12,300 kg
Max landing weight
—
Max payload
4,400 lb  ·  2,000 kg
Fuel capacity
Max cruise speed
627 kt  ·  722 mph  ·  1,161 km/h
Maximum speed
—
Cruise speed
—
Approach speed
—
Range
1,040 nm  ·  1,200 mi  ·  1,930 km
Fuel burn
—
Ceiling
55,000 ft  ·  16,800 m
Rate of climb
18,300 ft/min  ·  93 m/s
Takeoff distance
—
Landing distance
—
(/) tap to zoom
(/)
Douglas F4D-1 Skyray of VF-102 ‘Diamondbacks’

Live fleet activity details

📡
Fetching live data…
All Active Aircraft Types
Flight Airline Reg Alt Speed Heading V/S

Operational Context

In 1947, the F4D Skyray was developed to target the need of the United States Navy for a fighter aircraft that was capable of interception and could smash a rival aircraft at a 50,000 feet altitude in just five minutes after the alarm started to sound. The USN also looked for an aircraft that succeeded the designs and studies of Alexander Martin Lippisch, a German aeronautical engineer and pioneer of aerodynamics.

The F4D Skyray featured a delta wing configuration with stretched, acutely-swept, rounded wings. It had a wingspan of 10.21 meters and a wing area of 51.7 square meters. The wing roots were thick which had the air intake that ensured smooth airflow into a single turbojet engine. Fuel was lodged in both sides of the wings and in under the fuselage. Slats were incorporated to enable the wing to operate at a higher angle of attack, and tailerons that unite the elevator functions for pitch control and the aileron for roll control.

The aircraft was initially planned to be powered by the Westinghouse J40, however, the manufacturing company had a conventional perspective and the supposed-to-be engine showed issues and was finally canceled. Instead, the F4D Skyray was fitter with the more powerful Pratt and Whitney J57 axial-flow afterburning turbojet engine. It had a two-spool 16-stage axial compressor and produced a maximum dry thrust of 10,200 lbf.

The Skyray had a maximum speed of 627 knots. It had a range of 610 nautical miles and a ferry range of 1,040 nautical miles. It could climb up to 55,000 feet and had a maximum payload of 2,000 kg.
