The Bombardier Challenger 350 is a mid-size business jet designed to access more airports than other competitor in its category. Its cabin cross-section is almost identical as those of large cabin long-range aircraft that makes it one of the most capacious cabins in its class.

Manufacturer:
Bombardier Aerospace
Country:
Canada
Manufactured:
2013 to: Present
ICAO:
CL35
Price:
US$26.67 million (2015)
Avionics:
Collins Aerospace Advanced Avionics
Engine:
2x Honeywell HTF7350
Turbofan
Power:
7,323 pound-force
Max Cruise Speed:
470 knots
870 Km/h
Approach Speed (Vref):
115 knots
Travel range:
3,200 Nautical Miles
5,926 Kilometers
Fuel Economy:
Service Ceiling:
45,000 feet
Rate of Climb:

Take Off Distance:
1474 metre - 4,835.90 feet
Landing Distance:
720 metre - 2,362.18 feet
Max Take Off Weight:
18,416 Kg
40,600 lbs
Max Landing Weight:
15,490 Kg
34,149 lbs
Max Payload:
1,542 Kg
3,399 lbs
Fuel Tank Capacity:
14,150 gallon
53,563 litre
Baggage Volume:
106 m3 / 3,743 ft3
Seats - Economy / General:
10 seats
Seats - Business Class:
Seats - First Class:
Cabin Height:
1.83 metre - 6.00 feet
Cabin Width:
2.19 metre - 7.18 feet
Cabin Length:
7.68 metre - 25.20 feet
Exterior Length:
20.9 metre - 68.57 feet
Tail height:
6.1 metre - 20.01 feet
Fuselage Diameter:
2.2 metre - 7.22 feet
Wing Span / Rotor Diameter:
21 metre - 68.90 feet
Wing Tips:
Canted Winglets

Challenger 350 Production

The Challenger 350 is a mid-size business jet designed and manufactured by Bombardier Aerospace. The improved variant made its maiden flight on March 2 2013.

In May 2013, the aircraft was announced at the European Business Aviation Conference and Exhibition (EBACE) in Geneva, Switzerland and scheduled to enter service next year.

On June 11 2014, it received its type certification from Transport Canada then on the 25 the of June from the US Federal Aviation Administration (FAA). On September 2 2014, the aircraft received certification from European Aviation Safety Agency (EASA).

NetJets Inc., a subsidiary of Berkshire Hathaway, placed a $7.3 billion order of 75 aircraft in June 2012. In June 2014, the first Challenger 350 was delivered. In 2018, 60 aircraft were delivered; After five years of service, the 300th was deployed in July 2019.

In November 2015, Flexjet, an American provider of fractional ownership aircraft, leasing, and jet card services signed a memorandum of understanding (MOU) with Bombardier for 20 units of Challenger 350.

Challenger 350 Design

The Challenger 350 has an exterior length of 20.9 meters, a height of 6.1 meters and a fuselage diameter of 2.2 meters. Its 21-meter wing features canted winglets that helps to increase aerodynamic performance. These winglets have less acute angle that reduce the wingtip vortex and the associated drag by deflecting the air that wants to escape over the tip back down.

The Challenger 350 is created for higher fuel-efficiency and longer-range capability. It is also intended to reduce downtime and features lowest direct operating cost through longer maintenance intervals and low parts cost.

Challenger 350 Cabin

The Challenger 350 features the quietest cabin with a 7.68-meter length, 2.19-meter width and 1.83-meter height. It is designed to minimize noise and maximize comfort because of its ultra-quiet ambiance.

Furnished with a standard entry door acoustic curtain and a galley pocket door, the sound of aircraft suppressing design provides an excellent productivity and comfort during flight.

The aircraft can seat up to a maximum of eight to ten passengers. These reclinable seats can be reclined at 180° to a fully-flat position for a more convenient relaxation.

The Challenger 350 cabin also features an integrated nice high-definition Cabin Management System (CMS). By using the CMS applications, personal electronic devices can be accessed. It has communications and entertainment in a single control at every seat, and two 22-inches high definition bulkhead monitors.

The aircraft cabin has a Lufthansa niceview 3D moving maps which provides worldwide, high-resolution 3D maps and virtual flights designed to create the ultimate flight information and viewing experience. It is also equipped with wi-fi connection and Iridium satellite phones.

Challenger 350 Avionics

Produced by Rockwell Collins, the aircraft is equipped with Pro Line 21 advanced avionics suite.

The avionics system has four Adaptive Liquid Crystal Displays (LCD), dual fleet management system (FMS) with Localizer Performance with Vertical Guidance (LPV) and Required Navigation Performance (RNP) approaches capability, Synthetic Vision System (SVS) that uses 3D to provide pilots with clear and intuitive means of understanding their flying environment, a MultiScan, a Weather Surveillance Radar (WSR) to locate precipitation, calculate its motion, and estimate rain, snow, hail, etc.

It has a dual Inertial Reference System (IRS) that provides inertial navigation data to user systems. It also includes dual GPS with Satellite-Based Augmentation Systems (SBAS), advanced Electronic Flight Instrument System (EFIS) and dual Very High Frequency (VHF) and High Frequency (HF) radios.

Other avionics include Traffic Collision Avoidance System (TCAS) that serves as an aircraft collision avoidance system designed to reduce the incidence of mid-air collisions between aircraft.

Want More of This?
We'll send you our latest and best content straight to your inbox
Featured Image

Challenger 350 Engine and Performance

The Challenger 350 is powered by Honeywell HTF7350 that has 7.3% improved take-off thrust with 7,323 lbf maximum power. Its hot-section modification and Full Authority Digital Engine (or electronics) Control (FADEC) gives it the same flat rating, strength, and accuracy.

The aircraft has a maximum take-off weight of 18,416 kg and 15,490 kg maximum landing. Its fuel tank capacity is 14,150 US Gal and maximum payload is 1,542 kg.

Want More of This?
We'll send you our latest and best content straight to your inbox
Featured Image
