Embraer Lineage 1000

The ultra-large jet built for VIP customization and extended range.

Overview

Embraer Brazil ICAO: E190 2008–Present Active $43 million (2009)

The Embraer Lineage 1000 is a VIP airliner derivative based on the Embraer E190 platform. Introduced in 2009, it offers multiple cabin zones and long-range capability. The aircraft targets high-end private and government customers.

Live Fleet Activity (E190)

📡

Fetching live data…

Specifications

Units
Engine
2 × GE CF34-10E turbofans
Engine type
Turbofan
Thrust
2 × 18,500 lbf · 82 kN
Avionics
Honeywell Primus Epic avionics
Wing tips
Blended tips
Seats
19
Crew
—
Cabin width
8 ft 10 in  ·  2.69 m
Cabin height
6 ft 6 in  ·  1.98 m
Cabin length
84 ft 6 in  ·  25.75 m
Exterior length
118 ft 11 in  ·  36.24 m
Tail height
34 ft 8 in  ·  10.57 m
Fuselage diameter
9 ft 6 in  ·  2.90 m
Wing span
94 ft 3 in  ·  28.72 m
Baggage volume
441 ft³  ·  12.5 m³
Gross weight
—
Empty weight
—
Max takeoff weight
120,000 lb  ·  54,500 kg
Max landing weight
101,000 lb  ·  45,800 kg
Max payload
9,600 lb  ·  4,350 kg
Fuel capacity
7,200 gal · 27,200 L · 21,800 kg (Jet A)
Max cruise speed
480 kt  ·  552 mph  ·  889 km/h
Maximum speed
—
Cruise speed
—
Approach speed
—
Range
4,600 nm  ·  5,290 mi  ·  8,520 km
Fuel burn
0.98 nm/gal  ·  0.48 km/L
Ceiling
41,000 ft  ·  12,500 m
Rate of climb
2,464 ft/min  ·  13 m/s
Takeoff distance
6,100 ft  ·  1,850 m
Landing distance
3,400 ft  ·  1,040 m
(/) tap to zoom
(/)
Falcon Aviation Services – Embraer Lineage 1000 ‘A6-HHS’

Live fleet activity details

📡
Fetching live data…
All Active Aircraft Types
Flight Airline Reg Alt Speed Heading V/S

Operational Context

Embraer Lineage 1000 — ultra-large VIP business jet

The Lineage 1000 first flew in 2007 and entered service in 2009. It retains the E190’s wing and systems while incorporating a luxury-configured cabin. The aircraft includes multiple seating and entertainment zones.

Powered by two General Electric CF34 turbofan engines producing approximately 20,000 pounds of thrust (89 kN) each, the Lineage 1000 cruises at around Mach 0.82, approximately 470 knots (870 km/h). Maximum takeoff weight exceeds 120,000 pounds (54,432 kg). The cabin typically accommodates 13 to 19 passengers in VIP configuration.

The Lineage 1000 provided airline-scale comfort in a private format. Production numbers were limited but distinctive. The aircraft remains in specialized service worldwide.
