Light Business Jets
Embraer Phenom 300
ICAO: E55P
Overview
The Embraer Legacy 450 was introduced in the 2010s as a super-midsize business jet. It shares design philosophy with the larger Legacy 500. The aircraft entered service in 2015.
Live Fleet Activity (E545)
📡
Fetching live data…
Specifications
Units
- Engine
- 2 × Honeywell HTF7500E turbofans
- Engine type
- Turbofan
- Thrust
- 2 × 6,540 lbf · 29 kN
- Avionics
- Rockwell Collins Pro Line Fusion
- Wing tips
- Blended tips
- Seats
- 9
- Crew
- —
- Cabin width
- 6 ft 10 in · 2.08 m
- Cabin height
- 6 ft 0 in · 1.83 m
- Cabin length
- 24 ft 0 in · 7.32 m
- Exterior length
- 64 ft 7 in · 19.69 m
- Tail height
- 21 ft 1 in · 6.43 m
- Fuselage diameter
- 7 ft 6 in · 2.28 m
- Wing span
- 69 ft 5 in · 21.17 m
- Baggage volume
- 148 ft³ · 4.2 m³
- Gross weight
- —
- Empty weight
- —
- Max takeoff weight
- 35,800 lb · 16,200 kg
- Max landing weight
- 32,500 lb · 14,700 kg
- Max payload
- 2,900 lb · 1,350 kg
- Fuel capacity
- 1,630 gal · 6,200 L · 4,900 kg (Jet A)
- Max cruise speed
- 515 kt · 593 mph · 954 km/h
- Maximum speed
- —
- Cruise speed
- —
- Approach speed
- 124 kt · 143 mph · 230 km/h
- Range
- 2,904 nm · 3,340 mi · 5,380 km
- Fuel burn
- 1.09 nm/gal · 0.53 km/L
- Ceiling
- 45,000 ft · 13,700 m
- Rate of climb
- 3,700 ft/min · 19 m/s
- Takeoff distance
- 3,900 ft · 1,190 m
- Landing distance
- 2,100 ft · 640 m
