The Faster Sibling of the 350 The Beechcraft King Air B200gt

Manufacturer:
Hawker Beechcraft
Country:
United States
Manufactured:
2008 to: 2011
ICAO:
B200
Price:
US$5.8 million (2008)
Avionics:
Collins Pro Line 21
Engine:
2x 2 X Pratt & Whitney PT6A-52
Turboprop
Power:
850 horsepower
Max Cruise Speed:
308 knots
570 Km/h
Approach Speed (Vref):
Travel range:
1,592 Nautical Miles
2,948 Kilometers
Fuel Economy:
3.34 nautical mile / gallon
1.634 kilometres / litre
Service Ceiling:
35,000 feet
Rate of Climb:
2450 feet / minute
12.45metre / second
Take Off Distance:
1005 metre - 3,297.20 feet
Landing Distance:
820 metre - 2,690.26 feet
Max Take Off Weight:
5,670 Kg
12,500 lbs
Max Landing Weight:
5,670 Kg
12,500 lbs
Max Payload:
1,043 Kg
2,299 lbs
Fuel Tank Capacity:
190 gallon
719 litre
Baggage Volume:
.861 m3 / 30 ft3
Seats - Economy / General:
8 seats
Seats - Business Class:
0
Seats - First Class:
0
Cabin Height:
1.45 metre - 4.76 feet
Cabin Width:
1.37 metre - 4.49 feet
Cabin Length:
5.08 metre - 16.67 feet
Exterior Length:
13.36 metre - 43.83 feet
Tail height:
4.52 metre - 14.83 feet
Fuselage Diameter:
1.5 metre - 4.92 feet
Wing Span / Rotor Diameter:
16.58 metre - 54.40 feet
Wing Tips:
Blended Tips

This updated and improved version was the Model B200, which entered production in 1981.It was fitted with PT6A-42 engines, still rated at 850 shp (630 kW), but with improvements that resulted in greater aircraft performance. Other changes included increased maximum pressurization (to 6.5 psi differential) and changes to the cockpit layout. The Model 200C gave way to the Model B200C the same year, with the first Beechcraft Model B200T and Beechcraft Model B200CT being modified from a B200 and B200C respectively, the following year. Commencing in 1984 the B200, B200C and their derivatives were fitted with a revised landing gear retraction mechanism, actuated by hydraulic rams powered by an electric pump installed in the LH wing. This replaced the earlier electro-mechanical retraction system of gearboxes, drive shafts and chains and sprockets that was a throwback to the Twin Bonanza. At the same time the propellers fitted were changed from 3-bladed Hartzells to 3-bladed McCauleys. 47 B200Cs built that year were delivered to the U.S. military, with dozens more of a similar standard ordered in subsequent years, but not given official civil model designations. News source Wikipedia.
